There are a number of available lines styles ranging from dotted lines to more traditional CAD lines. Only the selected layer can be changed each time.Īn annotation layer is placed at the top of the drawing, so that your comments stay on top of the drawing content. Layers can be hidden or shown using the menu at the bottom, or by using the eye symbol.
Layer names are taken from the original file. Object count for the number of items within a layer makes for quick reference. Hide and show the layers you are looking to work with in the drawing. The 1:1 tool is a quick way of returning the drawing back to 100% zoom. You can also drag a zoom frame around the area of the drawing you would like to zoom into. Hold the Option (alt) key down and click to zoom out. Use the Zoom tool to zoom in and out of the drawing. It will display a live measurement as you drag the cursor. The Measure tool is used for doing a quick measurement between two points in the document. To change the fonts and styles you can use the Text menu item and its options. Once finished typing you can resize, move and change the attributes of the text. The Text tool is used for placing a text box in the document and typing your comments for annotations. Once the shape is drawn you can resize, move and change the attributes of the shape. The Ellipse tool is for drawing out your annotation ellipses for commenting on the drawing. It is designed to act as an alternative to the scrollbars.
The Hand tool is used to pan and move the window view. The Arrow or Cursor tool can be used for selecting your annotation and text, resizing, drawing selection frames and navigating the applications and its options.
